Description
NOTE: This Product is Downloadable Only. Single User License, Non-printable and Non-Device Transferable . Requires eMail address and contact information of End User.
This guide includes everything needed for repair and rework of electronic assemblies and printed circuit boards! IPC-7711B/7721B Rework, Modification and Repair of Electronic Assemblies has received a complete procedure by procedure update to assure applicability to both lead free and traditional SnPb soldered assemblies. This single volume includes all previously published changes and several new procedures for BGAs (including reballing) and flex-print repair.
Part 1 General Requirements has also been updated for ease of use and provides important direction and guidelines for all procedures. This section includes procedures common to rework, repair and modification.
Part 2 is IPC-7711B and the procedures include tools, materials and methods to be used in removing and replacing surface mount and through-hole components.
Part 3 is IPC-7721B and includes procedures for modifying assemblies and accomplishing laminate and conductor repairs.
This guide is provided in a three ring binder for easy updating. Users can insert company specific procedures, or remove just the pages needed for a specific job to help keep the workbench clear. Future updates can be downloaded FREE from www.ipc.org/downloads. Many procedures have color illustrations to help the user understand the guide. Supersedes IPC-7711, IPC-7721 and IPC-R-700.
Over 300 pages.
Released November 2007.
IMPORTANT: Single-Device DRM-Protected Document
This document has single-device/user digital rights management (DRM) protection. This document will only be accessible by a single user on a single device. If you are purchasing this DRM-protected document for another user, you will need to provide contact information for that user when placing your order.
