Description
NOTE: This Product is Downloadable Only. Single User License, Non-printable and Non-Device Transferable . Requires eMail address and contact information of End User.
Now updated to Revision H of the latest IPC-A-610 industry standard for the Acceptability of Electronic Assemblies, this Training & Reference Guide illustrates critical acceptance criteria for the evaluation of through-hole solder connections.
Useful as a training aid in the classroom, or on the shop floor, QRG-PTH contains computer generated color illustrations of component, barrel and solder-side perspectives of a plated-through-hole. Each drawing clearly shows the minimum acceptable condition for requirements such as land coverage, vertical fill, wetting of lead, land and barrel and contact angle.
QRG-PTH-H also contains high quality color microphotographs of the major solder defects and conditions such as nonwetting, corrosion, projections, fractures, lead protrusion and disturbed joints with pictures of both tin-lead and lead free solder joints. The appropriate specification/paragraph references from the IPC-A-610G are included for each of the acceptance criteria for further verification.
IMPORTANT: Single-Device DRM-Protected Document
This document has single-device/user digital rights management (DRM) protection. This document will only be accessible by a single user on a single device. If you are purchasing this DRM-protected document for another user, you will need to provide contact information for that user when placing your order.
